– 9 –
Note: Follow the disassembly procedure in the numerical order given.
FRONT PANEL ASS’Y
SECTION 2
DISASSEMBLY
1
Push the button
(release).
A
2
Remove the front panel ass’y
to the direction of the arrow
A
.
COVER ASS’Y
2
1
3
cover ass’y
1
2
