Sony XR-C5200 Service Manual

– 18 –
• Waveforms
– MAIN Board –
1 IC21 1 (XT OUT)
2 IC501 !∞ (XT IN)
3 IC501 !£ (OSC IN)
0.2 Vp-p
97.6 ns
1.7 Vp-p
30.5 µ s
1.3 Vp-p
54.2 ns
2.7 Vp-p
27 µ s
– KEY Board –
1 IC901 ^º OSC
