MHC-V02
5
DESTINATION ABBREVIATIONS
The following abbreviations for model destinations are used in this
service manual.
• Abbreviation
AR : Argentina model
AUS : Australian model
CND : Canadian model
E4 : African model
E12 : 220-240 V AC area in E model
E93 : 240V AC area in E model
LA9 : Latin-American model
MY : Malaysia model
RU : Russian model
TH : Thai model
DESTINATION SETTING METHOD
The destination information isn’t written in the MOTHERBOARD
board for the service.
Therefore, when the MOTHERBOARD board is replaced, be sure
to perform the destination setting (Important work).
Note 1: The initial setting destination of the MOTHERBOARD board for
the service is temporary set as “LATIN”. The message “LATIN
(T)” is displayed on the screen display panel.
Note 2: When distinguishing the destination of the product, refer to the
“MODEL IDENTIFICATION” on page 4.
Note 3: If destination setting isn’t performed, it is possibility to occur the
defect to each operation of this unit.
Note 4: Destination would be locked if it has been changed for 5 times.
Procedure:
1. Press two buttons of the [x] and [TUNING + >] simultane-
ously for 10 seconds during the demo mode.
2. It enters the destination setting mode, the message
“D XXXXX” is displayed on the screen display panel.
3. Press [ +] / [ ―] button to select the destination based on the
set’s country.
Screen
display
Destination
code
Country
“D ASIA
” SP6, TH1 Southeast Asia countries
“D INDIA” E12 India
“D ME AFC” E3, E93, E4,
SA2, EA3
Middle East & Africa countries
“D OCEANI
” AU1 Australia & New Zealand
“D JAPAN
” J1 Japan
“D BRAZIL” BR1 Brazil
“D N AME” UC2, CA2 America & Canada
“D LATIN” LA9, AR2 Central & South America
countries (except Brazil)
“D RUSSIA” RU1 Russia & CIS countries
“D EUROPE
” CEL, CEK Europe countries
(except CIS country)
4. Press [
N] button to confi rm the selection.
5. “COLD RST” appears on the screen display panel. The system
automatically turn on and off once. After that, “SONY” appears
on the screen display panel. Please be sure that the system stay
at demo mode fi nally before switch off the power supply.
6. Mode in “PANEL TEST MODE” on page 15 again to confi rm
on the model & destination.
TEST DISCS
Use following TEST DISC when this unit confi rms the operation
and checks it.
• For CD
Part No. Description
3-702-101-01 DISC (YEDS-18), TEST
4-225-203-01 DISC (PATD-012), TEST
J-2501-307-A DISC (HLX-A1), TEST
NOTE OF REPLACING THE MOTHERBOARD MOUNT-
ED PC BOARD
When MOTHERBOARD mounted pc board is replaced, it is nec-
essary to change the below parts which located between heat sink
(MB) and MOTHERBOARD mounted pc board (Refer page 32).
Part No. Description
4-745-015-01 SHEET, THERMAL
IF ERROR CODE APPEARS ON THE DISPLAY
See the following table for the corrective action.
Error code Corrective action
“PROTECT5”/
“PROTECT6”
Immediately unplug the AC power cord
(mains lead), and check if anything is
blocking the ventilation openings of the
unit. After you have checked and found no
problems, reconnect the AC power cord
(mains lead), and turn on the system. If the
issue persists, contact your nearest Sony
dealer.
“PROTECTX”
(“X” is a number
other than 5 and 6)
Contact your nearest Sony dealer.
