Soozier A91-132 - Page 9

8
Assembly instructions
63
1
49
63
49
5
59
Step 2
61
Attach the Frot support(5)
to the Base frame(1) with
M10x65 Bolt(49)x2and 10
Washer(61)x4andM10 Nut(63)x2
Attach the Front stabilizer(16)to the
Front support(5)withM10X40
(61)X2
φ
Bolt(59)X2andM10 Nut(63)X2and Washer
61
16
61
