Technical specifications
Sophos AP 15
Chassis Plastic housing, white
Maximum throughput 300 Mbit/s
LAN interfaces 1 x 10/100/1000 Base-TX
Supported WLAN standards 802.11 b/g/n 2.4 GHz
Antenna 2 x detachable dipole antenna (2 dBi) Connector type: RP-SMA
Frequencies / channels ETSI FCC
2.412–2.472 GHz (Channels 1-13) 2.412-2.462 GHz (channels 1-11)
Power supply 12 Vdc / 1 A
Power consumption 2.5 W (max.)
Power-over-Ethernet 802.3af, 802.3at
Dimensions W x H x D 194 x 32 x 115 mm
Weight 260 g
Temperature range Operating: 0°C to 45°C Storage: -20°C to 60°C
Humidity (non-condensing) 0% to 90%
Mounting Desktop / wall
Supported security standards WPA/WPA2, WEP, 802.1X (RADIUS)
Number of supported SSIDs 8
Regulatory compliance CE FCC
Radio: EN 300328 CFR 47, Part 15 Subpart C
EMC: EN 301489-1, EN 301489-17 CFR 47, Part 15 Subpart B
EMF: EN 50385 FCC 1.1310, IEEE C95.1
Safety: EN 60950-1 N/a
