1
2
Decreasing Set Point (psi)
1000
Increasing Set Point (psi)
9
5
0
100
200
300
600
900
600 900 1200 1500
1
2
Decreasing Set Point (psi)
1750
Increasing Set Point (psi)
9
45
1200
1500
Adjustable Dead Band
Pressure Switches
Step 1: Adjustable Range
Step 2: Housing
5V1-LA3-N6-C1A-YY
Service Description Designator
Non-Hazardous
Locations
Hazardous
Locations
(UL Listed/CSA Certified,
ATEX and SAA Approved
Snap Switch)
Weathertight for non-hazardous service.
NEMA 4, 4X & IP65
Electrical conduit connection: 3/4” NPT(F)
Material: 356 aluminum
Use LA or SA switching element and terminal
block.
Shipping weight: 4 pounds (2 kgs)
See cutaway view on page 2; dimensions on
page 14.
V1
Explosion proof and weathertight. NEMA 4, 4X &
IP65. Class I, Group A, B, C, D;
Class II, Group E, F, G; Division 1 & 2
Electrical conduit connection: 3/4” NPT(F)
Material: 356 aluminum
Use AG switching element; hermetically sealed SS
capsule
Shipping weight: 5 pounds (2.5 kgs)
V3
Overrange 2500 psi 170 bar
Proof 3875 psi 267 bar
Overrange 2500 psi 170 bar
Proof 3875 psi 267 bar
5V1-LA3-N6-C1A-YY
