Sorelle 1070-E - Page 9

Page 9
SORELLE
(DRF)Right Front Corner Post (1 pc)
(DLF)Left Front Corner Post (1 pc)
(ERB)Right Back Corner Post (1 pc)
(ELB)Left Back Corner Post (1 pc)
(I)Top Cap (2 pcs)
ELB
ERB
DLF
DRF
55mm Allen Bolts (8 pcs)
Wood dowels(10 pcs)
)d(
Gap (8 pcs)
)g(
)scp 01( stloB nellA mm24)b(
(c)17mm Allen Bolts (4 pcs)
d
d
(f)20mm Allen Bolts (8 pcs)
