Sorelle CAPE COD - Crib Assembly; Left Crib End Assembly; Center Crib End Assembly

Page 7
Crib Assembly
Left Crib End with Left Corner Post Assembly
Center Crib End with Middle Corner Post Assembly
Attach the Left Crib End(A1) to
the Left Corner Post(E1)
by using the 54mm bolt(c),
As shown in the pictures.
c
c
c
c
Attach the Center Crib End(B1) to
the Center Corner Post(F1)
by using the 54mm bolt(c) 2pcs,
As shown in the pictures.
