Sorotec COMPACT 0403 - Page 12

Page 11 / 22
Assembly instructions
Compact-Line kit
www.sorotec.de V 2.1.0
• Slide two carriages
14
onto the linear rails on
each side; the following should be noted:
- Ground, blank surfaces on the long sides
of the carriage point upwards towards the
tabletop.
- Equip the carriage with straight grease
nipples so that they point outwards (red
arrows in Figure 6).
• Screw the end plates
28
/
29
to the proles
with 2 at-head screws M12x30
N1
each;
Slightly counter-tighten the screws.
Note
„At the back“ of the Compact-Line slot table is
where there are four threaded holes on the un-
derside for mounting the xed bearing of the X-
spindle.
• Screw the bracket
32
to the underside of the
table top with M8x16 screws
S2
and washers
X
; Slightly counter-tighten the screws.
• Screw the brackets
32
to both end plates
28
/
29
with cylinder head screws M8x20
S3
and
ange nuts
T
; Slightly counter-tighten the
screws.
• Tighten the mounting screws in the following
order:
- pan head screws
(end plates on proles of the table top)
- cylinder screws (angles on table top)
- cylinder screws / ange nuts (angles on end
plates)
Fig. 6: Carriage X, end plates and brackets
N1
29
N1
32
30
32
14
14
28
• Guide the ball screw
4s
through the hole in
the front plate and screw the xed bearing
4f
to
the table top with 4 cylinder screws M6x40
E3
;
Slightly counter-tighten the screws.
• Slide the oating bearing unit
4l
onto the free
end of the ball screw and screw it to the table top
with two cylinder screws M6x40
E3
; Slightly
counter-tighten the screws.
• Install the snap ring on the end of the ball
screw.
Fig. 7: X-axis spindle and reference switch
E3
X
25
24
U
A1
E3
30
4s
4f
4l
28
29
J2
S1
Note
The fastening screws of the bearing units are
only tightened after alignment. If necessary,
observe the additional instructions for the elect-
rical installation kit when installing the reference
switch.
• Equip the switch carrier X with two cylinder
screws M8x12
S1
and washers
X
, loosely
unscrew the hammer nuts
J2
at the rear.
• Position switch carrier X
25
, threading
hammer nuts into the T-slot of the prole. Slightly
tighten the screws to turn the hammer nuts 90° in
the T-slot.
• Place the reference switch
24
with underlying
shim and screw it to the switch carrier
25
with
washers
U
and cylinder head screws M3x16
A1
.
