Preparing profiles
▶
Position the
installation adapter.
Note:
Pressing on the "Press" surfa
ce lets you
position the installation adapter at the
corresponding height.
▶
Repeat the
se steps until all installation
adapters h
ave been positioned.
Step 3 — Positioning
the installation
adapter
3
4
Click!
Click!
