MA 00057 | 2022-01-11 | 5
16
Attaching componen
ts
Attaching frames
.
▶
Determine the position.
▶
Position the frame between
the installation
adapter pair.
▶
Secure the frame to t
he profiles with screws.
▶
Repeat these steps un
til all frames have been
attached.
M6 x 14
1
2
4x
2
Nm
༔
༐
16
18
