© Sortimo International GmbH MA 00057 | 2022-01-11 | 5 19
Attaching components
Fitting the drawer H8/H10/H12
4x
4x
2x
2x
M6 x 16 M6 x 16
2
1
7,5 Nm
7,5 Nm
