Sortimo SR5 - Folding parallel vice

© Sortimo International GmbH MA 00057 | 2022-01-11 | 5 62
Attaching components
Folding parallel vice
Hinweis: A frame or shelf needs to be fitted to ensure the stability of the side profile at a distance
of three grids below or above, starting from the middle of the upper connection.
1
2
3
5 mm
22 mm
39 mm
M8 x 20
M8
M6 x 12
4,8 x 25
M6 12x8
M4 x 4
