Table 7-7. Refrigeration System: RT6000 Centrifuge
(keyed to figure 7-10)
ITEM P/N DESCRIPTION QTY.
1
83185
Condenser Assembly, 60 Hz, 115 Vac 1
83184
Condenser Assembly, 50 Hz, 200 Vac 1
2 07631
Transformer Assembly, 50 Hz only (Not available)
1
3
12208 Rectifier (Sold in kit)
1
4
07687
Transformer Assembly, Brake 1
5
66665
Choke, Filter, 21 MH, 5 ADC 1
6 63022 Lockwasher, Split, 5/16 x 0.056, SST 1
7 60821 Screw, Cap, Socket Hex Head, Steel Cad Plate, 5/16-18 x
3/4" Ion
4
8
63085
Flatwasher, SST, 0.169 I.D. x 0.304 O.D. x 0.032" Thick *
9 63015 Lockwasher, Split, SST, 8 x 0.047" Thick **
10 60967 Screw, Machine, Pan Head, Steel, No. 8-32 x 3/8" Long 10
11
60948
Screw, Machine, Pan Head, Slotted, Steel Cad Plate, UNC.
No. 8-32 x 5/8" Long
1
12
64401
Spacer, Round, 1/2" Diameter, (50 Hz only) 4
13
64695
Screw, Machine, Pan Head, Slotted, SST, UNC. No. 8-32 x
7/8" Long, (50 Hz only)
4
14
67829
Fan Blade, Tecumech Compressor 1
15
67828
Motor Fan, 60 Hz
67839
Motor Fan, 50 Hz 1
16
07662
Rubber Mat, Compressor 1
17
07585
Suction Line Tubing Assembly, Refrigeration 1
18
67831
67840
Relay, Overload, Compressor, 60 Hz
Relay, Overload, Compressor, 50 Hz
1
19
67827
67838
Start Capacitor, 60 Hz
Start Capacitor, 50 Hz
1
20
07582
Tubing, Sight Glass to Filter 1
21 64748 Clamp, Microgear, 1/2-7/8" Diameter Range, SST 2
22
66452
Insulation Tape, Self-Adhering 1
23
67343
Expansion Valve, Thermostatic 1
24
07595
Tubing Assembly, Access Valve to Condenser 1
25
67370
Filter/Drier 1
26
67850
67851
Switch, Overload, 60 Hz
Switch, Overload, 50 Hz
1
*Quantity: 10 for 60 Hz; 14 for 50 Hz
**Quantity: 11 for 60 Hz; 15 for 50 Hz
