CENTRIFUGES RT6000 and T6000 CENTRIFUGES
Table 7-8. Parts: Console Assembly
(keyed to figure 7-11) (continued)
ITEM P/N DESCRIPTION QTY.
22
60074
Nut, Hex, SST, No. 6-32 5
23 67692 Fastener, Floating Treelok 1
24 67882 Cord Stock, 1/8" Diameter 1
25 67717 Loctite® 495 A/R*
26
12216**
Temperature Control P.C. Board Assembly 1
27 07622 Bracket, Heatsink, 1" Long RT6000 Only 1
28 63914 Compound, Thermal, 8 oz. Jar A/R*
29 60074 Nut, Hex, SST, No. 6-32 11
30
60522
Flatwasher, SST, 5/32 I.D. x 3/8 O.D. x 0.031" Thick 6
31
63011
Lockwasher, Split, No. 6, SST, 0.031" Thick 6
32
61132
Screw, Machine, Pan Head, Slotted, SST, UNC, No. 6-32 x
3/8" Long
4
33
60930
Screw, Machine, Pan Head, Slotted, SST, UNC No. 6-32 x
1/4" Long
8
34 61711 Lockwasher, Intternal, No. 6 x 0.021" Thick 8
35 07620 Heatsink Bracket
37 63005 Lockwasher, Split, SST, No. 4 x 0.025" Thick 8
38
12216***
Motor Controls P.C. Board Assembly 1
39
67330
Rocker Switch, Smooth, Black, 20A, 227 Vac 1
40 ---- Circuit Breaker 1
67300
• 60 Hz, 2-Pole, Rocker, 15A, 250 Vac
67360
• 50 Hz, 2-Pole, Rocker, 8A, 250 Vac
1
41 ---- Resistor Assembly 1
07623
• 60 Hz, 33k Ω, 1/2" Wide
07624
• 50 Hz, 68K Ω, 1/2" Wide
* As required.
** PN 12216 is an upgrade kit that contains Temperature control P.C. Board PN 07841, Motor Controls P.C.
Board PN 07848, and Optical Pickup P.C. Board PN 07940. If the centrifuge has already been upgraded with
this kit, you only need to order Temperature Control P.C. Board PN 07841.
*** If the centrifuge has already been upgraded with this kit, order motor control board P.C. Board PN 07848.
Rev. 2/2002 7-49
