Table 8-6. Parts: Drive Assembly, PN 07884
(keyed to figure 8-11)
ITEM P/N DESCRIPTION QTY.
1 07528 Plate Assembly, Drive 1
2
68658
Belt, V-drive, 3/16 wide x 29.5" Long, Polyflex 1
3
67399
Spring, Extension, 0.360 O.D. x 1.75 Long x 0.058"
Wire Diameter-
1
4
07609
Hook, Spring Retaining 1
5 63832 Nut, Hex, SST, No. 10-24 2
6 07589 Plate, Motor Mounting 1
7 61231 Screw, Machine, Round Head, Slotted, SST, UNC No.
4-40 x 3/8" Long
1
8 67446 Flatwasher, Nylon, 0.129 I.D. x 0.25 O.D. x 0.031"
Thick
1
9 63005 Lockwasher, Split, SST No. 4
10 62396 Screw, Machine, Pan Head, Slotted, SST, UNC No. 4-
40 x 5/8" Long
2
11 61072 Flatwasher, No. 4, SST, 1/8 I.D. x 1/4 O.D. x 0.022"
Thick
2
12 61560 Lockwasher, External, Steel No. 4 2
13
62716
Microswitch, SPDT 1
14
62245
Insuator, Fish Paper 1
15
07887
RT6000B and T6000B Motor Assembly, 115V 1
16 12810
Armature Kit (Not available)
1
17
61652
Flatwasher, SST, No. 10, 13/64 I.D. x 7/16" O.D. x
0.031" Thick
1
18 07586
Disk, Optical, Pickup 1
19 64301 Screw, Cap, Socket Hex Head, Steelm UNF, No. 10-32
x 1/2" Long
1
20 63017 Lockwasher, Split, No. 10, SST, .047" Thick 7
21
07940
Optical Pickup P.C. Board Assembly 1
22
66680
Screw, Cap, Socket Hex Head, Unc, No. 10-24 x 3/8
long
3
