SORVALL
®
CENTRIFUGES RT6000B and T6000B CENTRIFUGES
Serial Numbers Below 9101800
Table 8-8. Parts: Console Assembly
(keyed to figure 8-13) (continued)
ITEM P/N DESCRIPTION QTY.
22
60074
Nut, Hex, SST, No. 6-32 5
23 67692 Fastener, Floating Treelok 1
24 67882 Cord Stock, 1/8" Diameter 1
25 67717 Loctite® 495 A/R*
26
07841
Temperature Control P.C. Board Assembly 1
27 07622 Bracket, Heatsink, 1" Long RT6000 Only 1
28 63914 Compound, Thermal, 8 oz. Jar A/R*
29 60074 Nut, Hex, SST, No. 6-32 11
30
60522
Flatwasher, SST, 5/32 I.D. x 3/8 O.D. x 0.031" Thick 6
31
63011
Lockwasher, Split, No. 6, SST, 0.031" Thick 6
32
61132
Screw, Machine, Pan Head, Slotted, SST, UNC, No. 6-32 x
3/8" Long
4
33
60930
Screw, Machine, Pan Head, Slotted, SST, UNC No. 6-32 x
1/4" Long
8
34 61711 Lockwasher, Intternal, No. 6 x 0.021" Thick 8
35 07620 Heatsink Bracket
36 60463 Nut, Hex, SSt, No. 4-40 8
37 63005 Lockwasher, Split, SST, No. 4 x 0.025" Thick 8
38
07848
Motor Controls P.C. Board Assembly 1
39
67330
Rocker Switch, Smooth, Black, 20A, 227 Vac 1
40 ---- Circuit Breaker 1
67300
• 60 Hz, 2-Pole, Rocker, 15A, 250 Vac
67360
• 50 Hz, 2-Pole, Rocker, 8A, 250 Vac
1
41 ---- Resistor Assembly 1
07623
• 60 Hz, 33k Ω, 1/2" Wide
07624
• 50 Hz, 68K Ω, 1/2" Wide
* As required.
Rev. 2/2002 8-55
