SORVALL
®
CENTRIFUGES RT/T6000D and RT/T60000B CENTRIFUGES
Serial Number 9101800 and Above
Table 9-7. Parts: RT6000B (SN 9101800 and Above) and RT6000D
(keyed to figure 9-20)
ITEM P/N DESCRIPTION QTY.
1 07524 Cover, Access 1
2
67351
Screw, Phillips, Pan Head, No. 8-32 x 3/8" Long 4
3
63936
Lockwasher, External Tooth, No. 8, SST 1
4 67381 Insulation, Tape, Vinyl, Closed Cell Foam, 3/16 Thick x 3/8"
Wide
1
5
67301
Transformer, Power 1
6 83051 Overlay, Access Cover, RT6000B/D 1
7 07684 Seal, Cover, Insulation 1
8
67699
Receptacle, Plug, Three-Prong, 60 Hz, 15A, 250 Vac OR 1
67379 Receptacle, Plug, Three-Prong, 50 Hz, 10A, 115/250 Vac 1
9
61095
Flatwasher, No. 4 2
10
63006
Lockwasher, Split, Steel, No. 4 2
11 60463 Nut, Hex, Steel, No. 4-40 2
12
67378
Power Cord, 3 Conductor, 115V, 60 Hz, 15A 1
67823
Power Cord, 3 Conductor, 250V, 50 Hz, 10A 1
13
66643
Jack, Banana, Double Insulated, Miniature 1
14 67310 Insulation, Tape, Vinyl, Close Cell Foam, 1/8" Thick x 1/4"
Wide
1
15 67312 Screw, Phillips, Pan Head, No. 8-32 x 3/8" Long 3
16
67311
Split Washer, Split, Black, No. 8 x 0.040" Thick 16
17
07959
Brake Resistor 1
18
60171
Flatwasher 2
19
63936
Star Washer 2
20
60184
Nut, Hex 2
21
61597
Screw, Machine, Pan Head, Slotted, SST, No. 10-32 x 3/8"
Long
47
22
63016
Lockwasher, Split, No. 10 x 0.040" Thick 40
23
67302
Hinge 2
24 67312 Screw, Machine, Pan Head, Slotted, Black, No. 8-32 x 3/8" 16
25
90721
Cap Screw, Socket Head, No. 8-32 x 3/8" Long 2
26 67313 Screw, Machine, Flat Head, 82o countersink, Black No. 10-32
x 3/8" Long (Not available)
2
27
07506
Door Assembly 1
28
07583
Cover Assembly, Kydex® acrylic resin 1
29
07550
Door Seal 1
30
67852
Cap, Polyethylene, Black 4
Rev. 2/2002 9-69
