SORVALL
®
CENTRIFUGES RT/T6000D and RT/T6000B centrifuges
Serial Number 9101800 and Above
Table 9-8. Parts: T6000B (SN 9101800 and above) and T6000D
(keyed to figure 9-21) (continued)
ITEM P/N DESCRIPTION QTY.
56 60674 Screw, Machine, Flat Head, 82o countersink, No 6-32 x
3/8" Long
6
57
90818 Nut, Speed, 10-24 (Not available)
2
58
60074
Nut, Hex, SST, No. 6 1
59 07642 Shield Assembly, Insulating, P.C. Board 1
60
61321
Flatwasher, No. 10 1
61
67330
Switch, Brake 1
62
67300♣
♣♣
♣
Switch, Power, 60 Hz 1
67360♣♣
♣♣♣♣
♣♣
Switch, Power 1
63
64877
Woodruff Key, 3/32 x 3/8" 1
64 07572 Support, Block Shaft 1
65
60023
Truarc® Retaining Ring, External, 1/4", SST 15-7PH 4
66
67380
Flatwasher, SST, 0.169 I.D. x 1
67
60522
Flatwasher, SST, 0.169 I.D. x 0.304 O.D. x 0.032 1
68 83091 Gasket, 5/8 Wide, 1/4" Thick A/R!
69 63305 Flatwasher, Steel Cad Plate, 0.187 x 0.687 O.D. x
0.063” Thick
2
70 60674 Screw, Machine, 6-32, SST 1
71 83010 Overlay, Switch, RT6000B/D 4
72
12944♦
♦♦
♦
12974♦♦
♦♦♦♦
♦♦
Knob Assembly, Latch Control, RT6000B/D 1
73
61682
Screw, Set, Hex Socket, Cup Point, Aly Steel Black
Oxide, No. 8-32 x 7/16” Long
1
74
67351
Screw, Phillips, Pan Head, No. 8-32 x 3/8” Long 2
75 83009
Console (Not available)
1
76 83100 Main Harness, RT6000B/D 1
77 07631
Transformer Assembly, 50 Hz only (Not available)
1
78
12208 Rectifier (Sold in kit)
1
79
07687
Transformer Assembly, Brake 1
80
66665
Choke, Filter, 21 MH, 5 ADC 1
81 67312 Screw, Phillips, Pan Head, No. 8-32 x 3/8” Long 3
! As required.
♣
♣♣
♣ For S/N 9303042 and above, use PN 91602 together with overlay PN 83137.
♣♣
♣♣♣♣
♣♣ For S/N 9303042 and above, use PN 91603 together with PN 83137.
♦
♦♦
♦ For RT6000B with SN 9101800 to 9302766; T6000B with SN 9101800 to 9302716; RT6000D with SN below 9302369;
T6000D with SN below 9302328.
♦♦
♦♦♦♦
♦♦ For RT6000B with SN 9302767 and above; T6000B with SN 9302717 and above; RT6000D with SN 9302370 and
above; T6000D with SN 9302329 and above.
Rev. 2/2002 9-75/9-76
