Table 9-9. Parts: Drive Assembly, PN 07884
(keyed to figure 9-22)
ITEM P/N DESCRIPTION QTY.
1 07528 Plate Assembly, Drive 1
2
68658
Belt, V-drive3/16" Wide x 29.5" Long, Polyflex x 3/8"
Long
1
3
67399
Spring, Extension, 0.360 O.D. x 1.75 Long x 0.058"
Wire Diameter
1
4
07609
Hook, Spring Retaining 1
5 63832 Nut, Hex, SST, No. 10-24 2
6 07589 Plate, Motor Mounting 1
7 61231 Screw, Machine, Round Head, Slotted, SST, UNC. No.
4-40 x 3/8"Long
1
8 67446 Flatwasher, Nylon, 0.129 I.D. x 0.25 O.D. x 0.031: 2
9 63005 Lockwasher, Split, SST, No.4 3
10 62396 Screw, Machine, Pan Head, Slotted, SST, UNC No. 4-
40 x 5/8" Long
2
11 61072 Flatwasher, No. 4, SST, 1/8 I.D. x 1/4 O.D. x 0.222"
Thick
2
12 61560 Lockwasher, External, Steel No. 4 2
13
62716
Microswitch, SPDT 1
14
62245
Insulator, Fish Paper 1
15
07887
RT6000B and T6000B Motor Assembly, 115V 1
16
12810 Artmature kit (Not available)
1
17
61652
Flatwasher, SST, No. 10, 13/64 I.D. x 7/16 O.D. x
0.031" Thick
1
18
07586
Disk, Optical, Pickup 1
19 64301 Screw, Cap. Socket Hex Head, Steel, UNF, No. 10-32 x
1/2" Long
1
20 63017 Lockwasher, Split, No. 10, SST, .047 Thick 7
21
07940
Optical Pickup P.C. Board Assembly 1
22
66680
Screw, Cap, Socket Hex Head, UNC, No. 10-24 x 3/8"
Long
3
23 63019 Lockwasher, Split, 1/4, SST, 0.047" Thick 2
24
61141
Nut, Hex, SST, No. 1/4-20 3
25
65548
Shock Mount 4
26 07956 Mounting Bracket, Imbalance Detector 1
27 07957 Imbalance Detector Assembly 1
