INSTALLATION
1. Main Body
2. Base
3. Washer
4. Screw
5. Speaker Net
1. Assembled the wooden base to the main body by the supplied screws and washers as the g.1
above.
2. The speaker net can take out and reassemble as Fig.2 above.
6. Tweeter
7. Remote Sensor
8. Loud Speakers
9. Woofer
1
5
7
6
8
9
2
3
4
Fig.1
Fig.2
