SOUNDMASTER NR50 - Front View; Location of Controls

NR50 / English Instruction Manual
1
LOCATION OF CONTROLS
FRONT VIEW
TURNTABLE
1
ON/STANDBY button
12
Volume knob
2
FUNCTION button
13
Play Mode button
3
RECORD button
14
Sleep/Timer button
4
OPEN/CLOSE button
15
INFO button
5
LCD display
16
SCAN button
6
CD tray
17
MEM/CLOCK-ADJUST button
7
Remote sensor
18
PRESET EQ button
8
Power LED indicator
19
USB socket
9
PLAY/PAUSE button
20
3.5mm Aux-In jack
10
STOP button
21
3.5mm Headphone jack
11
SKIP DOWN / UP button
22
TUNING/FOLDER/MEM.
PRE/ENTER knob
23
Turntable lock screw
26
Pick-up holder
24
Tone arm lever
27
Spindle adaptor
25
Turntable speed selector
