NR917 / English Instruction Manual
5
PHONO
1. Set the FUNCTION SWITCH to the PHONO position. The display shows “PH”.
2. Put the record on the turntable.
Note: If you want to play a single record, insert the 45 rpm adaptor in the center of the
turntable and then place the record.
3. Set the SPEED SELECTOR to 33 ⅓ , 45 or 78 RPM according to the size of the record.
4. Take out the stylus guard of the tone arm, then place the tone arm on the record carefully.
5. Adjust the VOLUME CONTROL to adjust the desired sound level.
6. To stop operation, lift up the tone arm carefully and return it to the tone arm rest.
CASSETTE
1. Set the FUNCTION SWITCH to the PHONO position. The display shows “PH”.
2. Insert the cassette and the unit starts playback of the cassette.
3. During playback, to wind fast forward, press the CASSETTE F.FWD/EJECT button half
inwards. Then the CASSETTE F.FWD/EJECT button is kept in the middle height position. To
return to normal playback, slightly press the CASSETTE F.FWD/EJECT button again. Then
the CASSETTE F.FWD/EJECT button resumes to the highest position.
4. To eject the cassette tape, press the CASSETTE F.FWD/EJECT button completely inwards.
Then the CASSETTE F.FWD/EJECT button is kept at the lowest position.
RECORDING
NOTE! The recording is only applied to phono, BT, CD and cassette mode.
When playing a record or cassette, insert the USB, and the red light turns on.
1. Press the button “R” to start recording, and the red light turns on.
2. Press the button “R” again to stop recording, and the red light bright turns off. The recorded
files are saved in the USB folder which is named “JL_REC”.
How to play the recorded file in the USB
During USB play, press the or button to select the recorded file. The recorded files are
saved at the end of the USB files and arranged according to the recording time.
TECHNICAL SPECIFICATION
Power supply
: Use only the supplied power adapter
Power input
: 220-240V~ 50/60Hz
Power output
: 12V 2A
FM range
: 87.5 – 108MHz
IMPORTER
Wörlein GmbH Tel.: +49 9103 71 67 0
Gewerbestrasse 12 Fax.: +49 9103 71 67 12
D 90556 Cadolzburg Email: service@woerlein.com
Germany Web: www.woerlein.com
