4" & 3" MPOWER
®
FASCIA LIGHTS
ENGLISH 0000JL 1123 REV C
4" & 3" MPOWER
®
FASCIA LIGHTS
FUNCTION TABLES
Changing the function table is only enabled when the LED module is in a flashing mode (disabled in cruise or steady ON
functions.) The functional operation of the LED module can be changed while applying the +V to the Red wire with the
black wire connected to ground. When the light is flashing, momentarily connect the White wire to ground for >4S and
<5S (light will go steady high, steady low, off, steady high, steady low) then release. The function table will now advance
to the next table (table 1 to table 2, table 2 to table 3, or table 3 to table 1. In the case that the custom table is pro-
grammed, the order is 1 to 2, 2 to 3, 3 to 7 (custom), and 7 to 1.) Repeat above process until required function table is ac-
tive. AFTER SELECTION: The light will "wink" to indicate which of the new tables is selected. Custom table will "wink" 7 times.
ELECTRICAL INSTRUCTIONS CONTINUED:
FUNCTION TABLE 1
WIRE LIGHT
RED R/W WHT SINGLE DUAL TRI
+9-32V FLASH FLASH DUAL
FLASH TRI
+9-32V CRUISE STEADY CLR 2
STEADY CLR 3
+9-32V +9-32V FLASH STEADY CLR 2
STEADY CLR 3
+9-32V NO OP NO OP
NO OP
+9-32V +9-32V LOW PWR FLASH FLASH CLR 1
FLASH CLR 1
+9-32V +9-32V CRUISE FLASH CLR 2
FLASH CLR 2
+9-32V +9-32V +9-32V LOW PWR FLASH FLASH DUAL
FLASH CLR 3
FUNCTION TABLE 2
WIRE LIGHT
RED R/W WHT SINGLE DUAL TRI
+9-32V FLASH FLASH CLR 1
FLASH DUAL
+9-32V +9-32V CRUISE FLASH DUAL
FLASH TRI
+9-32V STEADY CLR 1 STEADY CLR 2
STEADY CLR 3
+9-32V +9-32V STEADY CLR 1 STEADY CLR 2
STEADY CLR 3
+9-32V +9-32V +9-32V STEADY CLR 1 STEADY CLR 2
STEADY CLR 3
+9-32V NO OP NO OP
NO OP
+9-32V +9-32V STEADY CLR 1 STEADY CLR 2
STEADY CLR 3
FUNCTION TABLE 3
WIRE LIGHT
RED R/W WHT SINGLE DUAL TRI
+9-32V FLASH FLASH DUAL
FLASH TRI
+9-32V
FLASH
LOW PWR
FLASH DUAL
LOW PWR
FLASH TRI
LOW PWR
+9-32V +9-32V
FLASH
LOW PWR
FLASH DUAL
LOW PWR
FLASH TRI
LOW PWR
+9-32V NO OP NO OP
NO OP
+9-32V +9-32V
FLASH
LOW PWR
FLASH DUAL
LOW PWR
FLASH TRI
LOW PWR
+9-32V +9-32V
FLASH
LOW PWR
FLASH DUAL
LOW PWR
FLASH TRI
LOW PWR
+9-32V +9-32V +9-32V
FLASH LOW PW
R
FLASH DUAL
LOW PWR
FLASH TRI
LOW PWR
