1.800.338.7337 / www.soundoffsignal.com
11
4" & 3" MPOWER
®
FASCIA LIGHTS
ENGLISH 0000JL 1123 REV C
4" & 3" MPOWER
®
FASCIA LIGHTS
COLOR SWAP
This function is only valid for dual and tri-color light modules
and can only be changed when the light module is in a flash-
ing mode (disabled for single color modules and when light
module is operating in cruise or steady ON functions). When
the light is flashing, momentarily connect the white wire to
ground for >2S and <3S (light will go steady high, steady
low, off) then release. The light module will switch between
Color Swap OFF and Color Swap ON. When Color Swap is
OFF, the 1st color will flash 1st on a dual/tri color pattern.
When Color Swap is ON, the 2nd color will flash 1st on a
dual/tri color pattern.
SIMULTANEOUS/ALTERNATE
This function can only be changed when the LED module is
in a flashing mode (disabled in cruise or steady ON func-
tions) and only has an effect when at least 2 LED modules
have the green sync wire connected together. When the
light is flashing, momentarily connect the white wire to
ground for >3S and <4S (light will go steady high, steady
low, off, steady high) then release. The light module will
switch between Simultaneous and Alternate each time this
sequence is done. To have light modules flash simultane-
ously, both light modules need to be set to the same se-
quence type (Set-Up Table). To have light modules flash
alternately, the light modules need to be set to different
sequence types (Set-Up Table).
ADVANCE PATTERN
Flash pattern can only be changed when the LED module is
in a flashing mode (disabled in cruise or steady ON func-
tions). When the light is flashing, momentarily connect the
white wire to ground for >250mS and <1S (light will go
steady high) then release. The flash pattern will advance to
the next pattern. If the light module was at the last pattern,
the pattern will reset to the 1st pattern.
ELECTRICAL INSTRUCTIONS CONTINUED:
BACKUP PATTERN
This function is only valid when the LED module is in a
flashing mode (disabled in cruise or steady ON func-
tions). When the light is flashing, momentarily connect
the white wire to ground for >1S and < 2S (light will go
steady high, steady low) then release. The flash pattern
will backup to the previous pattern. If the light module
was at the first pattern, the pattern will change to the last
pattern on the list.
PATTERN RESET
This function is only valid when the LED module is in a
flashing mode (disabled in cruise or steady ON functions).
When the light is flashing, momentarily connect the white
wire to ground for >5S and <6S (light will go steady high,
steady low, off, steady high, steady low, off) then release.
The flash pattern will reset to the 1st pattern in the list.
FACTORY RESET
This function is only valid when the LED module is in a
flashing mode (disabled in cruise or steady ON functions).
When the light is flashing, momentarily connect the white
wire to ground for >6S and <7S (light will go steady high,
steady low, off, steady high, steady low, off, steady high)
then release. The LED module will reset to: pattern=1,
Function Table=1, Color Swap=OFF, Simultaneous.
LOCKOUT CONFIGURATION WIRE
This function will disable the wire tap configuration mode
that is activated by holding the white wire to ground. The
lock out is activated by applying ground to the white wire
for >7 seconds and <8 seconds per the table below. The
function can be disabled by tapping the wire to ground
and releasing 8 times within 5 seconds. The light will
flash 8 times when the feature is enabled or disabled to
notify the user of a setting change.
SETUP TABLE
SECONDS USER INTERFACE
FROM TO VISUAL FEEDBACK ACTION TAKEN
0 1 STEADY-HIGH (60%) FORWARD ONE PATTERN
1 2 STEADY-LOW (30%) BACKWARD ONE PATTERN
2 3 OFF COLOR SWAP (OFF OR ON )
3 4 STEADY - HIGH (60%) SEQUENCE TYPE: SIMULTANEOUS OR ALTERNATE
4 5 STEADY - LOW (30%) SEE FUNCTION TABLE
5 6 OFF RESET TO PATTERN 1
6 7 STEADY-HIGH (60%)
FACTORY RESET (PATTERN 1, COLOR SWAP: OFF, SIMULTANEOUS)
SEPARATE COLOR CONTROL: OFF
7 8 STEADY - LOW (30%) LOCK OUT WHITE CONFIGURATION WIRE
If held longer than 8 seconds, the light will go back to flashing the current pattern and no action will be taken.
