1.800.338.7337 / www.soundoffsignal.com
12
4" & 3" MPOWER
®
FASCIA LIGHTS
ENGLISH 0000JL 1123 REV C
4" & 3" MPOWER
®
FASCIA LIGHTS
ELECTRICAL INSTRUCTIONS CONTINUED:
Connecting the Green wire to ground before applying power
to the Red or Red/White wires will place the LED module
into remote mode and the light output color will be directly
controlled by the input wires as shown below.
mpower® Secondary LED Light Remote Mode Functionality
Red Wire
Red/White
Wire
Single Color Dual Color Tri Color
Color
Swap=OFF
Color
Swap=ON
Color
Swap=OFF
Color
Swap=ON
Color
Swap=OFF
Color
Swap=ON
Cruise - Cruise Color 1 Cruise Color 1 Cruise Color 2 Cruise Color 1 Cruise Color 2
- Cruise Cruise Color 2
Cruise Color 1 Cruise Color 2 Cruise Color 1
Cruise Cruise Cruise Color 2
Cruise Color 1 Cruise Color 3 Cruise Color 3
Flash - Flash Color 1 Flash Color 1
Flash Color 2 Flash Color 1 Flash Color 2
- Flash Flash Color 2
Flash Color 1 Flash Color 2 Flash Color 1
Flash Flash Flash Color 2
Flash Color 1 Flash Color 3 Flash Color 3
Steady ON - Steady ON Color 1 Steady ON Color 1
Steady ON Color 2 Steady ON Color 1 Steady ON Color 2
- Steady ON Steady ON Color 2
Steady ON Color 1 Steady ON Color 2 Steady ON Color 1
Steady ON Steady ON Steady ON Color 2
Steady ON Color 1 Steady ON Color 3 Steady ON Color 3
Cruise Flash
Flash Color 2/Cruise
Color 1 during OFF
cycle of Flash
Flash Color 1/Cruise
Color 2 during OFF
cycle of Flash
Cruise Steady ON Steady ON Color 2
Steady ON Color 1
Flash Steady ON Steady ON Color 2
Steady ON Color 1
Cruise Mode Duty Cycle (@ 100Hz)
Input Light Output
40%
OFF
50%
5%
60%
10%
Low Power Flash D.C. (@ 100Hz)
Input Light Output
70%
30%
80%
40%
90%
50%
Cruise and Low Power Modes
For Cruise mode or Low Power control of the LED module,
the signal to the control wires must be 100 +/- 2Hz using
the duty cycle inputs listed below to produce the light
output.
REMOTE MODE: FOR USE WITH bluePRINT SYSTEM ONLY
