POWER AND GROUND
To assure maximum output from your amplifier, use high quality, low-loss power
and ground cables. Soundstream amplifiers incorporate gold-plated barrier
strips for maximum power transfer and protection from corrosion. The screw
terminals back out for use with spade
&
ring terminals. Determine from the chart
below the minimum gauge power and ground wire for your application.
.~
CIRCUIT BREAKERS/FUSES
EXTERNAL
Like all audio components, the Soundstream amplifiers must be fused near the
battery A fuse or circuit breaker must be located within
18”
of the battery This
will prevent a fire in the event of a shorted cable. See the chart below to
determine the value of your battery Fuse/circuit breaker.
INTERNAL
The Soundstream amplifiers are fused internally with automotive-type fuses.
The fuse is accessible on the left side of the amplifier.
Never replace the fuses
with a higher value than what is supplied.
T/~is
may reso/f in amplifier
damage and
will
void
the
warrantyt
(Continued on page 9)
Model
I
Amplifier Fuses
!
Battery Fuse/
Circuit Breaker
P203 (1) 30 amp automotive 40 amp
P205
(2) 20 amp automotive
50 amp
8
