13 PIN CONNECTOR
SYSTEM PROGRAMMING - Menu 1
PAGE 12
INSTALL MANUAL
SYSTEM WIRING DETAILS
ARS.1
NOT USED
GREEN/WHITE
GREEN/BLACK
PINK/WHITE
RED/WHITE
ORANGE/WHITE
ORANGE/BLACK
BROWN
GRAY
PURPLE/WHITE
GRAY/BLACK
PURPLE
GREEN
OUTPUT FOR FACTORY ALARM RE-ARM
OUTPUT FOR FACTORY ALARM DIS-ARM
NEGATIVE STARTER OUTPUT
OUTPUT FOR TRUNK RELEASE ACTIVATION
NEGATIVE ACCESSORY OUTPUT/ AUXILIARY OUTPUT 2
AUXILIARY OUTPUT 1/ PROGRAMMABLE OUTPUT
BRAKE SWITCH INPUT (+) WHEN BRAKE IS PRESSED
HOOD PIN SWITCH INPUT
TACH WIRE INPUT
DIESEL WAIT TO START/ (+) TRIGGER TO START
POSITIVE DOOR PIN INPUT
NEGATIVE DOOR PIN INPUT
BLK/WHT
1-GREEN/WHITE Rearm(-) (Programmable) - Supplies one .75 second pulse when locked
and one .75 second pulse after remote start shutdown. Factory alarm re-arm/ RAP shutdown.
2-GREEN/BLACK Disarm(-) - .75 second pulse when unlock button is pressed and one
.75 second pulse before remote start activation. For factory alarm dis-arm/ “wake up”.
3-PINK/WHITE (-) Start/ Crank - Negative output during crank/ start.
4-RED/WHITE Trunk Release(-) (Programmable)- Output will activate when the Trunk
button is held for at least 3 seconds.
5- ORANGE/WHITE 2nd Acc (-) / Auxiliary Output 2 (Programmable) - Ground output at
the same time as the primary Accessory. output. This output can be programmed to activate as
an auxiliary output when the trunk and start buttons are held.
6- ORANGE/BLACK Auxiliary Output 1/ Programmable Output - Auxiliary Output 1
Programmable to (-) Ignition/ Car Finder and Dome Light Supervision with Car Finder.
7- BROWN Brake Switch input (+) - This wire must be connected to the wire at the
brake switch that changes to 12volts when the brake is pressed.
-
8- BLACK/WHT NOT USED
9- GRAY Hood Pin Input (-) - Connect this wire to the supplied hood pin switch.
If ground is detected on this input the remote starter will not activate.
10- PURPLE/WHITE Tach Wire Input (A/C) - This wire is used to to detect when the vehicle
has started. The Tach source is typically taken from a fuel injector, coil, coil pack or crank
position sensor. The Tach wire is generally found as the opposite from the common wire at the
coil or fuel injector.
11- GRAY/BLACK Wait to Start Input (+ or -) (Programmable) - On diesel vehicles
connect this wire to the wait to start or glow plug wire. The system will wait for the input to turn
off then remote start. A start delay may also be programmed to avoid this connection.
12- PURPLE Positive Door Input (+)- Connect this wire to the door pin switch if it
changes to 12volts when the door is opened.
13- GREEN Negative Door Input (-) Connect this wire to the door pin switch if it
changes to Negative when the door is opened.
