30
Installer Setup
Dry Contact Operation (setup step 66 - 67)
Dry Contact Polarity (setup step 66)
Open (Normally Open) - The dry contact is open until the connected device
closes the circuit.
Closed (Normally Closed) - The dry contact is closed until the connected device
opens the circuit.
Dry Contact Use (setup step 67)
CONDENSATE PAN - If CONDENSATE PAN is selected when the dry contact
is active, the thermostat will lockout the compressor terminal(s) and
“CONDENSATE PAN OVERFLOW” will appear on the display.
OCCUPIED - If OCCUPIED is selected, when the dry contact is active, the
thermostat will be forced into the programmed occupied mode / setpoints
and the ‘occupied’ icon will blink. This setting is useful for allowing a twist
timer to force occupied settings.
FDD - If FDD is selected when the dry contact is active, “EQUIPMENT
FAULT” will appear on the display.
HOLIDAY - If HOLIDAY is selected, when the dry contact is active, the
thermostat will be forced into the programmed unoccupied mode /
setpoints and the ‘unoccupied’ icon will blink.
DOOR SWITCH - If DOORSWITCH is selected, when the dry contact is active
for more than 3 minutes, the thermostat set points will switch to OF (off),
the equipment will turn off, and DOOR OPEN will appear on the display.
Skyport (setup step 71)
Set to ON to allow access to Skyport services or to OFF to not allow access to
Skyport services.
Local API (setup step 72)
Set to ON to allow third-party software to interface with your thermostat such as
home automation software.
Wired Sensor Type (setup step 44)
Specifies the use of the connected, wired sensor. The choices are: Remote, Supply,
Outdoor. Only the remote option allows control of the sensor.
(continued on next page)
