33
Installer Setup
Auxiliary Output Programming By Temp
If TEMP is selected for the Aux Output, the following setup steps will
appear:
Aux Output Temp Source (setup step 63) - Specifies what temperature
source will be monitored for controlling the programmable output. The
options are:
Thermostat - Temperature is monitored from the thermostat sensor.
Outdoor Sensor - Temperature is monitored from the Outdoor
temperature sensor.
Wired Remote - Temperature is monitored from a wired sensor
connected to the Remote Sensor terminals.
Aux Output Trigger Point Temp (setup step 64) - Specifies the temperature
from the above selected source above which the Aux Output is triggered.
A non-adjustable two degree deadband is applied to avoid frequent
triggering. The ‘N.O.’ (Normally Open) or ‘N.C.’ (Normally Closed) function
(Setup Step 56) can be altered to make the output trigger below the set
temperature. Temps are adjustable from 0 - 120 degrees Fahrenheit.
Press Fan To Clear All Messages (setup step 81)
This feature allows the user to clear all current error messages from the
display.
