Advanced Setup
This is normally done by the installer at initial installation.
Press NEXT
to advance
Press NEXT
to advance
Press NEXT
to advance
Page 17
Press NEXT
to advance
Continued
NEXT
NEXT
NEXT
NEXT
Enter advanced setup by sliding the Program Switch to
SET. When the clock is flashing, press the NEXT button for
5 seconds. Do not release the button until this screen
appears.
Use these buttons to
adjust the Cycles Per Hour
from 2 to 6.
d=no limit (zoning)
d1=d+no compressor
lockout (page 18).
Select backlight operation
when a button is pressed:
OFF: Never turns on.
2,4,6 or 8: Seconds back-
light will be on.
ON: Always on.*
Use these buttons to select
thermostat operation in
degrees C or F.
Use these buttons to
adjust the deadband
from 1 to 6 degrees.
OWNER'S MANUAL
S1-THEC11P5S
* ON is only available if the thermostat
is system powered.
To Next Page
