South Bend Tools SB1007 - Headstock Parts List

South Bend Tools
For Machines Mfd. Since 12/21 Model SB1007
-69-
PARTS
Headstock Parts List
R
R
E
E
F
F
P
P
A
A
R
R
T
T
#
#
D
D
E
E
S
S
C
C
R
R
I
I
P
P
T
T
I
I
O
O
N
N
R
R
E
E
F
F
P
P
A
A
R
R
T
T
#
#
D
D
E
E
S
S
C
C
R
R
I
I
P
P
T
T
I
I
O
O
N
N
1 PSB1007001 HEADSTOCK CASTING 43 PSB1007043 END COVER THREADED SHAFT (LONG)
2 PSB1007002 SPINDLE D1-4 44 PSB1007044 CONTROL PANEL BOX
3 PSB1007003 SPINDLE BEARING COVER (INBOARD) 45 PSB1007045 HEADSTOCK FRONT PANEL
4 PSB1007004 SPINDLE BEARING COVER (OUTBOARD) 46 PSB1007046 CONTROL PANEL PLATE (LOWER)
5 PSB1007005 SLIDING GEAR 55T 50 PSB1007050 TIMING BELT GATES HTD 710-5M-25
6 PSB1007006 COMBO GEAR 49T/27T 51 PSB1007051 FLAT WASHER 6MM
7 PSB1007007 SPACER 52 PSB1007052 CAP SCREW M6-1 X 12
8 PSB1007008 GEAR 32T 53 PSB1007053 CAP SCREW M6-1 X 16
9 PSB1007009 BUSHING 54 PSB1007054 TAPERED ROLLER BEARING 32008 FAG
9-1 PSB1007009-1 O-RING 17.8 X 2.4 P18 55 PSB1007055 CAP SCREW M8-1.25 X 20
10 PSB1007010 DRIVE SHAFT 56 PSB1007056 KEY 4 X 4 X 16
11 PSB1007011 COMBO GEAR 45T/17T 57 PSB1007057 CAP SCREW M5-.8 X 12
12 PSB1007012 GEAR 23T 58 PSB1007058 SET SCREW M8-1.25 X 15
13 PSB1007013 BEARING COVER 59 PSB1007059 STEEL BALL 6MM
14 PSB1007014 DRIVE PULLEY 60 PSB1007060 KEY 6 X 6 X 30
15 PSB1007015 PRELOAD NUT 61 PSB1007061 BALL BEARING 6305Z FAG
15-1 PSB1007015-1 SET SCREW M5-.8 X 6 62 PSB1007062 CAP SCREW M4-.7 X 16
15-2 PSB1007015-2 PLATE 4 X 4 X 2 63 PSB1007063 CAP SCREW M6-1 X 12
16 PSB1007016 BUSHING 64 PSB1007064 O-RING 8.8 X 1.9 P9
16-1 PSB1007016-1 OIL SEAL TC12 X 18 X 5 65 PSB1007065 EXT RETAINING RING 10MM
16-2 PSB1007016-2 O-RING 15.8 X 2.4 P16 66 PSB1007066 CAP SCREW M4-.7 X 12
17 PSB1007017 SHAFT 67 PSB1007067 TAPERED ROLLER BEARING 32009 FAG
17-1 PSB1007017-1 EXT RETAINING RING 12MM 68 PSB1007068 OIL SIGHT GLASS 3/8" NPT
18 PSB1007018 GEAR 32T 69 PSB1007069 HEX NUT M10-1.5
19 PSB1007019 GEAR 30T 70 PSB1007070 LOCK WASHER 10MM
20 PSB1007020 COMBO GEAR 32T/32T 71 PSB1007071 FLANGE SCREW M5-.8 X 95
21 PSB1007021 LOCK SHAFT 72 PSB1007072 COMPRESSION SPRING
21-1 PSB1007021-1 O-RING 15.8 X 2.4 P16 73 PSB1007073 FLAT WASHER 5MM
22 PSB1007022 FEED DIRECTION SHAFT 74 PSB1007074 CAP SCREW M5-.8 X 12
23 PSB1007023 SHIFT BLOCK 75 PSB1007075 EXT RETAINING RING 12MM
24 PSB1007024 SHAFT 76 PSB1007076 CAP SCREW M6-1 X 16
25 PSB1007025 SHIFT FORK 77 PSB1007077 OUTBOARD HEADSTOCK OIL GASKET
26 PSB1007026 COMPRESSION SPRING 78 PSB1007078 INBOARD HEADSTOCK OIL GASKET
27 PSB1007027 SLIDE BLOCK 79 PSB1007079 HEADSTOCK TOP COVER GASKET
28 PSB1007028 PLATE 80 PSB1007080 CONTROL PANEL PLATE (UPPER)
29 PSB1007029 O-RING COVER 81 PSB1007081 PRELOAD NUT RETAINER RING
30 PSB1007030 SHAFT END COVER 82 PSB1007082 CAP SCREW M6-1 X 18
31 PSB1007031 CAMLOCK 83 PSB1007083 BUSHING
32 PSB1007032 LOCK SCREW M8-1.25 X 18 84 PSB1007084 SHAFT END CAP
33 PSB1007033 LOCK PIN 85 PSB1007085 DRIVE SHAFT END CAP
34 PSB1007034 HEADSTOCK TOP COVER 86 PSB1007086 CAP SCREW M8-1.25 X 20
35 PSB1007035 BUSHING 87 PSB1007087 ELECTRICAL CABINET HINGE PIN 5.5 X 62MM
36 PSB1007036 HANDLE HUB 88 PSB1007088 STRAIN RELIEF 1/2" NPT ST METAL
37 PSB1007037 HANDLE M8-1.25 89 PSB1007089 STRAIN RELIEF 1/2" NPT 90D METAL
38 PSB1007038 ELECTRICAL CABINET 90 PSB1007090 ELECTRICAL BOX LOCK WITH KEYS (2-PC)
39 PSB1007039 ELECTRICAL CABINET DOOR W/LATCH 91 PSB1007091 CONTROL BOX LOCK WITH KEYS (2-PC)
40 PSB1007040 ELECTRICAL CABINET MOUNTING PLATE 92 PSB1007092 HANDLE HUB COVER LABEL 30MM, BLACK
41 PSB1007041 END COVER 93 PSB1007093 RUBBER PAD
42 PSB1007042 END COVER THREADED SHAFT (SHORT)
