-6-
For Machines Mfd. Since 12/21
Model SB1007
INTRODUCTION
Configuring the end gears will control the speed
of the leadscrew for threading or the feed rod for
power feed operations. The rotational speed of
these components depends not only on the end
gear configuration, but the spindle speed as well.
End Gears
Figure Figure 7. End gears. End gears.
To reduce the risk of
serious injury when using
this machine, read and
understand this entire
manual before beginning any
operations.
