Southwire MAXIS XD1 - Cautionary Safety Notes; Product Overview; Product Identification; Description of Operation

• Read and understand all the instructions and safety information in
this manual before operating or servicing this tool.
Description of Operation
The Maxis
®
XD1 Extreme Duty Circuit Puller is a high-speed cable
puller intended to pull branch and data circuits or small feeder wire
circuits through conduit. The Maxis
®
XD1 Extreme Duty Circuit
Puller was designed to fit on most manufacturer’s models of
18-volt cordless drills with ½” chuck adaptor. The Maxis
®
XD1
Extreme Duty Circuit Puller can be operated by one or two people.
5
6
IDENTIFICATIONIMPORTANT SAFETY INFORMATION
1. Removable Capstan
2. Adjustable Drill Cradle
3. Input Shaft Chuck Adaptor
4. Gear Box
5. Base Arm
6. Front Extension
7. Front Roller Payoff
8. Conduit Adaptor
9. 20 Degree Up Adjustment
10. Polyline/Mule Tape Pin
FAILURE TO OBSERVE THESE WARNINGS CAN RESULT
IN SEVERE INJURY OR DEATH
CAUTION
• Do not use if any parts are damaged as this can cause an unsafe
condition and lead to tool malfunction or failure.
• If tool is in disrepair, DO NOT USE. Have tool serviced at an
Authorized Southwire Repair Center.
FAILURE TO OBSERVE THESE WARNINGS CAN RESULT
IN SEVERE INJURY OR DEATH
CAUTION
1
2
3
4
10
9
5
6
7
8
