ADDITIONAL HELP
• Model # XD10
• Stock # 59190402
SPECIFICATIONS
Pulling Speed Low:
At 2,000 lbs. 11fpm
At 4,000 lbs. 10fpm
At 6,000 lbs. 9fpm
At 8,000 lbs. 8fpm
At 10,000 lbs. 7fpm
Pulling Speed High:
At 2000 lbs. 21fpm
At 4000 lbs. 18fpm
Recommended
Pulling Rope Size:
9/16” QWIKrope™, 7/8” Double-Braided
or 1” Double-Braided pulling rope with
minimum breaking strength of 30,000 lbs.
Length (folded): 70 inches
Width: 26 inches
Height Folded: 40 inches
Height Extension: 10 feet
Length Extension: 11 feet
Weight: 598 lbs.
