3.3 Install the power supply
Power M4X20*2
1
Install the power supply on the right
profile of the machine gantry with
two M4X20 scews, tighten the screws.
1
3 Assembly
3.1 Install the gantry
3.2 Install the display
M5X50*4
BaseGantry
1
Install the gantry on the base
with four M5X50 screws,
tighten the screws.
1 2
Disaplay
1
Install the display on the holder on the right of base.
1
2
2
Push it down diagonally to let it stuck on the holder.
