3.6 Install the filament holder
1
Install the filament plate on the top of the
machine with two M5X10 screws.
2
Install the filament holder.
*The shown in the picture is the back
of the machine, when the back of the machine is facing
you, the filament holder is facing to the left
1
Filament holder M5X10*2
2
* (This part of the filament holder)
faces the front of the machine
3.7 Connection lines
*Please select the correct
input voltage to match your
local mains (230V or 115V).
Exp3
Y
Z2
Power
Extruder Kit
X
Z1
EN
To Next Page
