Sovol SV06 - Extruder Kit; Control Box

3.4 Install the extruder kit
3.5 Install the control box
Extruder kit M3X5*3
1
Install the extruder kit on the slide base with
three M3X5 screws, tighten the screws.
1
Install It Here
Control box
1
Please turn the aircraft switch on
the control box hanging plate to
the left from the locked state
to the unlocked state.
1
Control box
2
Install the control box on the hanging plate.
3
Press the entire control box down to let it be locked on
the hanging plate.
4
Re-rotate the aircraft switch to the locked state.
2 3 4
EN
