Model SCM Air to Water Heat Pump — Installation, Operation & Maintenance Manual
Section 12: Replacement Parts
Figure 23 Replacement parts
PART NUMBER DESCRIPTION VENDOR PART NUMBER
SCM036 SCM060
45R20000-320009 Carel Temperature Sensor, 10K NTC015WP00 (IP68,-55F to 212F, 5 Ft., 10K Ohm)
45R20000-360006 Compressor Contactor HCC-1NU04A A
45R2000-3136 Fan Motor Controller CONVON/OFF
45R2000-3137 Carel Expansion Board MCH2000020
45R2000-3138 Carel Controller MCH2000010
45R2000-3157 Soft Start PCB 2000-3157
45R2000-3501 Fan Motor Capacitor CBB61 (35μF/450VAC)
45R2000-3603
Pressure Switch (0.30MPa/0.15MPa ± 0.05)
H20PS (0.02MPa/0.15MP)
45R2000-3606 Flow Switch HF68P/1"NPT
45R2000-3619 Relay, Circulator JQX-105F-4 (220-240V, 30A)
45R20000-370011 Transformer (220-230V to 11.5V 600mA) 41X26.5F (220~230VAC,50/60Hz, 11.5VAC,0.6A)
45R2001-3605
Pressure Switch (3.2MPa/4.4MPa ± 0.15)
H20PS (3.2MPa/4.4MPa)
45R2001-3608
Pressure Switch (2.8MPa/3.6MPa ± 0.15)
H20PS (2.8MPa/3.6MPa)
45R20000-140456 45R20000-140449 EEV SPF-16D32 (9.5kW)
45R2004-1437 4-Way Valve C03C01S/SHF-9H-35U / STF-0203G (R410A)
45R20000-330124 Fan Motor YY060-1206P01-004
45R3500-2701 Fan Blade 440×152 AS+20%GF
45R20000-110097 Compressor ATH290RN-C9LU
45R20000-110068 Compressor PA200M2CS-3MUU1
45R2000-3504 Compressor Capacitor CBB65 (35μF/450V)
45R2000-3505 Compressor Capacitor CBB65 (50μF/450V)
45R35018-120010 Tube in Shell Heat Exchanger GAH04-CM×2
45R35018-120012 Tube in Shell Heat Exchanger GAH03-CMF×2
45R35036-120011 Finned Coil Heat Exchanger 3 rows, Φ7.94mm
45R35036-120012 Finned Tube Heat Exchanger 3 rows, Φ7.94mm
45R40000-120006 Finned Tube Heat Exchanger 2 rows, Φ7.94mm
45R40000-120007 Finned Tube Heat Exchanger 2 rows, Φ7.94mm
45R20000-000025 Immersion Heater Element 240 VAC 3kW
