FIGURE 3.
Loosely assemble left leg to console with casting
bracket BETWEEN as shown with 1 1/2" bolt
and nut.
Assemble right leg to console same as Step 5.
Align and square console and tighten all
connections, Steps 4, 5, 6.
5
6
STEP 6
NOTE:
FIG. 3
LEFT
FRONT
VIEW
STEP 5
1 1/2" BOLT
NUT
STEP 6
STEP 5
1 1/2" BOLT
NUT
