G
ARM PLACEMENT - LEVEL 1A
Step 1: Place arms onto each shaft.
NOTE:
Shaft lengths and rotation arms are
not to scale in the illustration. Shafts
and arm placement at 1:1 scale are
shown in the tri-fold.
Rotation Arm A
Rotation Arm B
Rotation Arm C
F
G
B
K
M
L
O
P
0 300mm
0 300mm
0 200mm
0 200mm
0 200mm
0 200mm
0 200mm
0 200mm
86mm
272mm102mm59mm
90mm 133mm
117mm78mm
144mm
264mm105mm
51mm
55mm
