Spacerails Level 8 - Elevator Assembly Continued; Install Elevator Rings and Guards; Install Elevator Cover and Rail Clips

Page 10 Seaich Corporation, LLC. All rights reserved. www.seaich.com
|
Spacerails, LLC. www.spacerails.com
NOTE:
The Marble may
fall out of the
elevator if it
enters too fast.
Step 7: Attach Rail Clips to each
Elevator Ring as shown.
Step 4: Slide each Elevator Ring
into position on the support
shafts right-side up.
Step 6: Insert three Elevator Guards each in
the bottom two Elevator Rings.
Step 5: Place the Elevator Cover onto the
top of the elevator assembly.
NOTE:
Elevator Rings are
right side up when
tabs in red are
on the top.
550 mm
385 mm
200 mm
30 mm
0 mm
ELEVATOR ASSEMBLY CONTINUED
