Shaft Q
Shaft T
153
Shaft R
589
180
330
475
519
Shaft S
43
90
125
160
195
230
253
300
Attach
arm L-1
Attach
arm M-4
43
76
111
147
182
217
253
Attach
arm O-2
Attach
arm P-3
300
Shaft S and shaft T are suspended above
the base using Arm B connections From
shafts L, M, O, and P.
Shaft P
300
105
187
235
SHAFT ASSEMBLY CONTINUED
TOP
BASE
BACK
OF BASE
FRONT
OF BASE
SHAFT TO BASE ORIENTATION
