15
Item Qty. Part No. Description
1 1 600335 Base
2 1 901120 Strut, Left, Pole to Base
3 1 901121 Strut, Right, Pole to Base
4 1 FR908418 Top Pole Section (3.5 in Dia)
5 1 901829 Middle Pole Section (3.5 in Dia)
6 1 FR908179 Bottom Pole Section (3.5 in Dia)
7 2 108183 Wheel Bracket
8 2 266200 Wheel, 4 inches, Plastic, Black
9 2 10818201 Rod, Axle
10 2 203099 Nut, Ny-lock, 5/16-18
11 1 206273 Bolt, Hex, 1/2-13 x 4.5” Long
12 1 203131 Bolt, Hex Head, 5/16-18 x 5.0 Long
13 4 207550 Pushnut
14 12 203100 Hex Flange Nut 5/16-18
15 1 908415 Bracket, Pole Mount
16 2 204846 Carriage Bolt, 5/16-18 x 4.75 Long
17 1 60016401 Tube, Outer
18 2 204962 Bolt, Hex Head, 5/16-18 x 0.625 Long
19 1 108181 Plate, Pole Mounting
20 1 201518 Bolt, Hex Head, 5/16-18 x 2.75 Long
21 1 60028601 Front Cover
22 6 208505 Bolt, Carriage, 5/16-18 x 1.50 Long
23 4 206665 Bolt, Hex Head, 1/2-13 x 2 Long
24 6 203218 Washer, Flat, 5/16
25 2 203679 Bolt, Hex Head, 3/8-16 x 2 Long
26 4 208892 Bolt, Hex Flange, 5/16-18 x 1.625 Long
27 1 202528 Pin, Actuator Assembly
28 1 200503 Cover, Black OR
200504 Cover, Red
Item Qty. Part No. Description
29 3 205809 Bolt, Hex Head, 1/2-13 x 10.25 Long
30 4 208251 Spacer, Plastic, 0.50 I.D. x 0.13 Long
31 8 206340 Lock Nut, Hex 1/2-13
32 2 908375 Elevator Tube, Lower - Long
33 1 568091 Label, Height Adjustment & Moving
FR568091 Label, Height Adjustment & Moving, French*
34 1 Rim
35 2 908374 Elevator Tube, Upper - Short
36 2 208261 Spacer, Plastic, 0.53 I.D. x 2.38 Long
37 1 203470 Washer, Flat, 0.625 I.D. x .1.5 O.D.
38 1 600137 Cap, Pole Top
39 2 200520 Screw, 8#x3/4L, For Cover
40 2 900867 Triangle Plates
41 1 203617 Cap, Base, Black
42 1 208279 Reinforcement Bracket
43 1 Net
44 1 900033 Bracket, Slam Jam
45 1 206048 Bolt, Tee, 3/8-16, 3.25 Long
46 1 200318 Bracket, Reinforcement, Slam Jam
47 1 208760 Spring, Rim
48 1 203795 Nut, Special, 3/8-16
49 1 206089 Spacer, Plastic, 0.53 I.D. x 3.5 Long
50 4 201683 Spacer, Plastic, 0.53 I.D. x 1.5 Long
51 1 600165 Cap, Height Indicator
52 1 700009 Handle, Elevator Assembly
53 1 204872 Label, Height Indicator
54 1 Backboard, Glass
1 Backboard, Acrylic
55 1 80034403 Screw-Jack Assembly
56 2 203156 Bolt, Hex Head, 5/16-18 x 1 Long
NOTE: You may have extra parts with this model.
PARTS LIST - See Hardware Identifier
NOTE:
Hardware kit is designed for more than one
style of basketball system. Not all hardware
will be used.
