SPALDING NBA Arena - Section C & D: Elevator Assembly; Elevator Assembly Hardware

18
Item Qty. PartNo. Description
20 1 700009 Handle, Screw-Jack
21 1 80034403 Screw Jack
22 1 60016401 Sleeve, Screw Jack
23 1 600165 Cap, Screw Jack
24 1 202528 Pin, Handle
Item Qty. PartNo. Description
E1 1 201518 Bolt, Hex-Head, 5/16-18 x 2.75” Long
E2 1 203099 Lock-Nut, Nylon Insert, 5/16-18
203099Hex Locknut (Nylon Insert) 5/16-18
#E2 (1)
#E1 (1)
HARDWARELISTANDIDENTIFIER
EL00001
Hammer or Mallet
TOOLS REQUIRED FOR THIS SECTION
ELEVATOR TO POLE CONNECTION HARDWARE CARD
1/2”
(2) Wrenches
AND/OR
1/2”
(2) Socket Wrenches and Sockets
Extension
SECTION C:ELEVATORASSEMBLYPART1
