Step 1: Remove folded lift from box.
Step 2: Remove the bottom plastic caps, then the bottom bolt, nut and washers
on the side of the base bracket. Use the wrench tool to loosen the bolt if needed.
Step 3: Remove the plastic caps, then the bolt, nut and washers at the front of
the base bracket. Use the wrench tools if needed.
Step 4: To stand the mast upright, lift the mast upward 1” to clear the metal plate
at the bottom of the mast.
1
2
Metal Plate
Step 5: Reinsert and tighten the front and side bolts, nuts, washers to secure the
mast using the wrench tools. Reinsert the plastic caps after the screws are tightened.
Step 6: Remove the plastic cap, and then bolt, nut and washer at the top of the
mast. Use wrench tools if needed.
F600B Installation
