Description TrapJumper
Cable Length 40 m / 130 ft standard
Footage Counter Yes
Driving Force Manual (push rod)
Voltage 12v DC / 230v AC / 110v DC
Current Ex Power Supply 1.7 amp max
Battery Li-ion - 9 hrs running time
Operating Temp 14°F to 122°F / -10°C to +50°C
Charging Temp 50°F to 113°F / +10°C to + 45°C
Coiler Weight 11.8 kg / 26 lbs
Coiler Height 20.5" / 520 mm
Coiler Width 17.5" / 445 mm
Coiler Depth Folded 12.25" / 310 mm
Coiler Depth Unfolded 18.75" / 478 mm
LCD Size 10.4" diagonal
Resolution 720 x 576 RGB (SVGA)
LCD Viewing Angle 85° typical
IP Rating
Box- IP54 open, IP67 closed
Camera - IP68
Memory 32 GB SSD
Data Export
x2 USB 2.1, x1 SD card, x1
Ethernet, Wifi, 4G
Software
WinCan Embedded + WinCan
Web Basic, mina Survey
Output 800 x 600 SVGA, DE15
Sonde - frequency 512 Hz
Min. bend radius 76mm
Technical Data Overview
The TrapJumper is Spartan Tool's lightweight push-rod camera solution, designed to
provide both flexibility to navigate trap-bends while being strong enough to be pushed
the distance in abrasive pipes. The TrapJumper is fully compatible with the Explorer
control box, meaning that it is simple plug 'n play to start using the latest addition to the
Spartan range of products.
