SPE BEF200N - General Assembly Diagram: Bef200 N - Parts List 1

BEF200N
PARTS BOOK OIPB-S18001
15
GENERAL ASSEMBLY DIAGRAM: BEF200N – PARTS LIST 1
Item #
Part #
Description
QTY
Remarks
101
20025
BEF200N DRUM
1
102
6204
BEARING, 47MM X 20MM
4
103
7034
KNOB GRIP
1
104
9102
SIDE PLATE SPACER
1
105
9106
DUST SKIRT
1
106
9107
FRONT AXLE
2
107
9110
REAR AXLE ASSEMBLY
1
108
9113A
KEY, 16MM X 4MM
1
109
9114
HEX DRIVER BUSH
1
110
9115
SIDE PLATE BEARING HOUSING
1
111
9116
BEARING HOUSING ASSEMBLY
2
112
9117
SWING ARM BOSS
2
113
9118
SWING ARM PIN
2
114
9119
BUSHING, 26MM X 20MM
1
115
9120
WHEEL, 75MM
1
116
9121
WHEEL, 128MM
2
117
9122
YOKE & CLEVIS, M12
1
118
9123
BEARING, 55MM X 30MM
1
119
9124
BEARING, 47MM X 25MM
1
120
9125
DRIVE SHAFT SPACER
1
121
9126
PULLEY (GAS)
1
122
9127
PULLEY (EU)
2
123
9128
DRIVE PULLEY
1
124
9131
KEY, 30MM X 8MM
1
125
9132
CIRCLIP, 50MM
1
126
9133
CIRCLIP, 28MM
1
127
9135
HAND WHEEL WITH KNOB
1
128
9137
BELT (ELECTRIC & GAS)
1
129
9138
BELT GUARD
1
130
9140
DRIVE SHAFT
1
131
-
HONDA GX160 ENGINE
1
132
-
ELECTRIC MOTOR
1
133
9158
SPACER (GAS PULLEY)
1
134
9200
CHASSIS
1
135
9201
RIGHT SIDE PLATE
1
136
9202
MOTOR PLATE
1
138
9203
HANDLE ASSM (ELECTRIC VERSIONS)
1
138
9205
HANDLE ASSM W/SWITCH (GAS/PETROL VERSIONS)
1
139
9206
VACUUM PORT
1
140
9301
HEIGHT ADJUST BLOCK
1
141
9302
HEIGHT SCREW
1
142
9303
MAIN ROD
1
143
9304
PITCH BLOCK
1
144
9305
ADJUSTABLE HEIGHT TUBE
1
145
9308
PITCH HANDLE
1
146
9309
PITCH HANDLE ROD
1
147
9310
HANDLE SLEEVE
1
148
9311
WEAR PLATE
1
149
9312
HANDLE CAP
1
150
9313
HANDLE PLATE
1
151
9314
HANDLE TOP PLATE
1
152
9315
M8 LOCK HANDLE
1
153
9316
M8 SWING BOLT
2
154
9317
ROD END
1
155
9318
BUSHING
2
156
9321
SPACER
1
*USE PREFIX 90 WHEN ORDERING IN NORTH AMERICA*
