USING RS232

Settings

The serial baud rate for this protocol is 9,600bps. All serial communications use 8 data bits, no parity and one stop bit (8-N-1).

Serial hardware ow control (i.e., RTS/CTS and DTR/DSR) and software ow control (i.e., XON/XOFF) protocols are not used

and will be ignored.

Programming Commands

All command packets shall be of the following format:

*<command><parameter 1><parameter 2><CR>

Notes: Each <…> represents a single ASCII character. <CR> represents a carriage return.

The Controller will ACK each recognized command with an asterisk (*). The Controller will NACK each unrecognized com-

mand with a period (.).

TIME Series Controller Page 6

Command Equivalent Remote Button Action

*Z01<CR> Zone 1 Selects Zone 1 speakers

*Z02<CR> Zone 2 Selects Zone 2 speakers

*Z03<CR> Zone 3 Selects Zone 3 speakers

*Z04<CR> Zone 4 Selects Zone 4 speakers

Zone Command: *Z<parameter 1><parameter 2><CR>

Command Equivalent Remote Button/Action Action

*P00<CR> None Off Command

*P01<CR> None On Command

*P02<CR> On/Off On/Off Command

Power Command: *P<parameter 1><parameter 2><CR>

Command Equivalent Remote Button/Action Action

*S++<CR> Speaker Select + Scrolls Selected Speaker Forward 1

*S--<CR> Speaker Select - Scrolls Selected Speaker Back 1

*S01<CR> None Speaker 1 Select

*S02<CR> None Speaker 2 Select

*S03<CR> None Speaker 3 Select

*S04<CR> None Speaker 4 Select

*S05<CR> None Speaker 5 Select

*S06<CR> None Speaker 6 Select

*S07<CR> None Speaker 7 Select

*S08<CR> None Speaker 8 Select

*S!!<CR> None Cancels select mode

Speaker Select Command: *S<parameter 1><parameter 2><CR>

Command Equivalent Remote Button/Action Action

*R++<CR> Rotate Dial Clockwise Rotates Speaker Right

*R--<CR> Rotate Dial Counter-Clockwise Rotates Speaker Left

Rotate Speaker Command: *R<parameter 1><parameter 2><CR>

*R!!<CR> None Stop
