with the ON/OFF switch.
Maintenance
1) when not in use store the machine out of the reach
of children;
Have your power tool serviced by a qualied repair
person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained;
Component list
1. Front handle with safety switch
2. Safety guard
3. Blade
4. Blade sheath
5. Guard xing Screws
6. Battery pack
7. On/off switch
8. Charger (See Fig. A )
Technical data
Voltage:
No load speed:
Battery capacity:
Cutting diameter:
Cutting length:
Machine weight:
Charging time:
18V
1200/min
1.7Ah
14mm
42cm
2.7kg
3-5hr
Noise and vibration data
A weighted Sound Pressure 79dB (A)
A weighted Sound Power 87dB (A)
K
pA
&K
wA
: 3dB(A)
Wear ear protection when sound pressure is over
85dB (A)
Typical weighted vibration 1.55m/s
2
K=1.5m/s
2
WARNING: The vibration emission value
during actual use of the power tool can
differ from the declared value depending on the
ways in which the tool is used dependant on the
following examples and other variations on how
the tool is used:
How the tool is used and the materials is cut or
drilled.
The tool being in good condition and well
maintained
The use the correct accessory for the tool and
ensuring it is sharp and in good condition.
The tightness of the grip on the handles and any
anti vibration accessories are used.
And the tool is being used as intended by its
design and these instructions.
This tool may cause hand-arm vibration
syndrome if its use is not adequately
managed.
WARNING: To be accurate, an estimation
of exposure level in the actual conditions of
use should also take account of all parts of the
operating cycle such as the times when the tool
is switched off and when it is running idle but
not actually doing the job. This may signicantly
reduce the exposure level over the total working
period.
Help to minimize your vibration exposure risk.
Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate).
If the tool is to be used regularly then invest in
anti vibration accessories.
Avoid using tools in temperatures of 10
o
C or less.
Plan your work schedule to spread any high
vibration tool use across a number of days.
Accessories
1pc Safety guard
1pc Blade sheath
1pc Charger
1pc Battery pack
We recommend that you purchase your accessories
from the same store that sold you the tool. Use good
quality accessories marked with a well-known brand
name. Choose the type according to the work you
intend to undertake. Refer to the accessory packaging
for further details. Store personnel can assist you and
offer advice.
Operation instructions
NOTE: Before using the tool, read the
instruction book carefully
1. Charging your battery pack
WARNING! The charger and battery pack are
specically designed to work together so do
not attempt to use any other devices. Never insert or
allow metallic objects into your charger or battery pack
connections because an electrical failure and hazard
will occur.
2. Before using your cordless tool
Your battery pack is UNCHARGED and you must
charge once before use. When you charge the new
battery or one which has not been used for long
periods of time, it may not reach full charge until after
you have discharged it fully in use and recharge it
several times.
3. How to charge your battery pack (See Fig A)
Connect the battery charger to the power supply and
the green light will illuminate. Then, Put the charger
base on battery pack to make connections and the
light will turn to orange to show charging has started.
A discharged battery at normal ambient temperature
will take approximately 3-5 hours to reach full charge.
When charging is complete, unplug the charger and
remove the battery pack.
WARNING! When battery charge runs out after
continuous use or exposure to direct sunlight or
heat, allow time for the battery and tool to cool down
